Asus TUF Z390-Plus Gaming
This product is not available from any retailers on PriceMe. Please see related products
Reviews
Show all
7 years ago
Asus TUF Z390-PLUS Gaming
Asus' TUF-branded components are designed for extra durability – and they're also put together with entry-level builders in mind, which means features that should support easy construction and compatibility with other components.
7 years ago
Asus TUF Z390-PLUS Gaming Review
The Asus TUF Z390-Plus Gaming has good durability and a solid basic specification, but rivals that don’t cost much more tend to offer just as much here – and, in some cases, better connectivity and on-board slots and sockets.
7 years ago
ASUS TUF Z390-PLUS GAMING ATX Form, For Intel 8th/9th Gen LGA1151, Z390 chipset, 4x DDR4 - 4266Mhz, 2x M.2 USB3.1 Gen2 HDMI DP
Bought this to take an i5 9600k, and it's a great match. The board is solid, and the BIOS UI is reasonably user-friendly. The board is well-made and doesn't feel brittle like some others. I've bought Asus boards for a while as they've always been good, and this one is no exception
Product details
Product info
General
Chipset
Intel Z390
Design
Form factor
ATX
Cooling
Passive
Processor
Socket
Intel Socket 1151-V2
64-bit processor
Yes
Compatible processors
Celeron, Core i3, Core i5, Core i7, Pentium
Number processor sockets
One
Connectors
Display Port
Yes
Display Port version
1.2
Number Display Port Outputs
1 pc
DVI
No
eSATA
No
Headphone output
Yes
Microphone input
1 pc
PS/2
2 pc
S/PDIF
No
HDMI
HDMI
Yes
HDMI outputs
1 pc
USB Connectors
USB
Yes
USB type
USB (Type A)
USB 3.0/3.1 (Gen 1)
4 pc
USB 3.1 (Gen 2)
2 pc
Internal Connections
M.2
2 pc
Chassis fan connectors
2 pc
Internal S/PDIF
1 pc
Internal USB 2.0
4 pc
Internal USB 3.0/3.1 ports (Gen 1)
4 pc
SATA
Yes
SATA (total)
6 pc
SATA 6Gb/s
6 pc
SCSI controller
No
Image properties
Graphics card
No
Support for integrated graphics in CPU
Yes
Expansion slots
AGP slot
No
Mini-PCI
No
PCI Express Mini
No
PCI Express x1
4 pc
PCI Express x16
2 pc
PCI Express x4
No
PCI Express x8
No
PCI slots
No
PCI-X
No
PCI Express version
3.0
Features
Features
LED lihtin
Communication
Bluetooth
No
Ethernet connection RJ45
Yes
Network chip
Intel I219-V
Number of Ethernet connections
1 pc
Wireless network Wi-Fi
Yes
Compatibility
RAID controller
Yes
RAID type
0, 1, 10, 5
Graphics Card
Multiple graphics cards
Yes
Multi-GPU technology
CrossFireX
Sound Card
Sound card
Yes
Sound card chip
Realtek ALC S1200A
Memory
Memory Type
DDR4
ECC support
No
Maximum memory
64 GB
Memory slots
4 pc
Memory speed
DDR4-2133, DDR4-2400, DDR4-2666, DDR4-2800, DDR4-3000, DDR4-3200, DDR4-3300, DDR4-3333, DDR4-3400, DDR4-3466, DDR4-3600, DDR4-3733, DDR4-3866, DDR4-4000, DDR4-4133, DDR4-4266 Mhz
Miscellaneous
Manufacturer warranty
3 Years
Dimensions
Height
24.40 cm
Width
30.50 cm
